Motorola DIMETRA X Core User Manual

6802800U74-AN
Chapter 3: Site Preparation
81
Heat
AC
When
Charg
Heat AC
When
DC
-48
Heat
MTS 260 MHz
AC
AC
ing
Charg-
V
DC
Configuration
(W)
(W)
(W)
ing (W)
(W)
(W)
Comment
MTS4 with 1 BR
w. ATCC
240
230
625
290
235
225
Low power PA,
fans
MTS4 with 2 BRs
w. ATCC
375
355
755
410
365
345
Low power PA,
fans
MTS4 with 3 BRs
w. ATCC
620
590
1380
705
605
575
Low power PA,
fans
MTS4 with 4 BRs
w. ATCC
760
720
2005
835
745
705
Low power PA,
fans
TETRA TX 25 W
MTS2 with 1 BR
230
205
610
280
225
200
No combining,
low power PA
MTS2 with 2 BRs
430
380
810
470
420
370
Two TX ant.,
low power PA
NOTICE:
• All the values in the table are calculated from AC = 230 V
• Add additional 5% for 110 V
• Charging is up to 6 A per PSU
3.7.2.1.4
Power Loads and Heat Dissipation – Expansion Cabinet 260 MHz
Table 17: Typical Power Loads and Heat Dissipation Values – Expansion Cabinet 260 MHz
Configuration
Expansion Cabi-
net Consump-
AC
When Heat AC
DC
tions MTS 260
Heat
Charg When
-48
Heat
MHz Configura-
AC AC
ing Charg-
V
DC
tion
(W) (W)
(W) ing (W)
(W)
(W)
Comment
TETRA TX 10 W
MTS4 Exp. Cab.
w 1 BR w. ATCC
240 230
625 290
235
225
Low power PA,
fans
MTS4 Exp. Cab.
w. 2 BRs w.
ATCC
375 355
755 410
365
345
Low power PA,
fans
MTS4 Exp. Cab.
w. 3 BRs w.
ATCC
620 590
1380 705
605
575
Low power PA,
fans
MTS4 Exp. Cab.
w. 4 BRs w.
ATCC
760 720
2005 835
745
705
Low power PA,
fans
