Motorola Droid Turbo 2 - Page 25

Moto X Force/DROID Turbo 2
BASEBAND TROUBLESHOOTING GUIDES
MOTOROLA CONFIDENTIAL
3.5mm Headset Jack
Loudspeaker Port
Front View
Earpiece Port
Top View
Mic 1 (Primary) & Mic 4
(Quaternary) Port
Mic 2 (Secondary) Port
Mic 3 (Tertiary)
Microphone Port
Back View
Mic 5 (ANC) Port
Deco removed to
expose actual port
locations
Audio Devices
