Motorola Droid Turbo 2 - Page 47

Moto X Force/DROID Turbo 2
BASEBAND TROUBLESHOOTING GUIDES
MOTOROLA CONFIDENTIAL
Check PMIC
All
Regulators
Turn On?
Yes
Check Power
Up Sequence
Check USB
Enumeration
PS_HOLD =
1.8V
Yes
Replace MSM
(U1000)
No
No
Use XRay to find
Shorts near
PM8994 (U2000)
PMI8994 (U2500)
Use Ohmmeter to
look for short circuits
on all power rails
Use Power Sequence Slides as a reference
Replace MSM
(U1000)
Replace PMIC
Check PMIC
