To unlock the screen, touch the unlock icon and drag it
to the right.
Lock and Unlock ScreenCharge and Power On
Your Device
Home ScreenGoogle Account Set-up Touch Screen Tips
Notications
Your display will go dark if untouched for a period of
time. Press the Power/Lock Key
to wake it up again.
This lock screen will appear.
Remember to fully charge your battery before use.
NOTE: Your device is always on when being charged.
To turn your device on or
o, press and hold the
Power/Lock Key
.
Your home screen has 3 panels. Touch the Home Key
to go to the home screen.
When you turn your device on for the rst time, you will
be prompted to set up your existing Gmail account. If you
don’t have one, you can create one. Touch the Android to
start the process.
There are several touch motions recognized by the device:
Touch – to select a menu item or open an application
Touch and hold – to grab an object that you want to
move or open an option menu
Drag – to move an object or scroll slowly on a list or web
page
Flick – to scroll quickly on a list or web page (touch the
screen again to stop the scrolling action)
Double tap – to zoom in/out on a web page or picture
Notications let you know when an event has occurred
that may require your attention such as voicemail, missed
calls, text messages, etc.
To view your notications, touch the status bar at the top
of the screen and drag it down. Touch each notication
to view the details. When you are done, touch the Home
Key
to return to the home screen.
Now your Gmail™, Google contacts, and Google calendar
events will all be loaded to your device automatically.
Use the area below to record your Google account
information for future reference.
Username: ___________________________@gmail.com
Password: _____________________________________
Search by Voice: Touch
icon then speak search
word to start search
Slide your nger to the
right to see the left panel
of your Home screen.
Slide your nger to the left
to see the right panel of your
Home screen.
Center Panel
Left Panel Right Panel
Google Search: Touch
text box to open virtual
keypad (slider QWERTY
must be closed), then
enter text to start
search
Applications Button:
Touch button to access
all applications stored
on your device.
Personalize: Touch and
hold any open area on
your home screen to add
shortcuts, widgets, folders
or change wallpaper.
To remove an item from
your home screen, touch
and hold the item then
drag it to a trash bin that
will appear at the
bottom of the screen.
To rearrange the items on
your home screen, touch
and hold each item then
drag it to its new position.
Sleep Mode: From any screen
you can put your display into
sleep mode. Just press the
Power/Lock Key
. This will
prevent false key presses as well
as help you conserve battery life.
3.5mm Audio Jack
Slider QWERTY Keypad
Search Key
Micro USB Charger/Data Port
Touch Screen
Volume
Keys
Battery
Door
Speaker
5 Megapixel
Autofocus
Camera
Flash
Device Layout
Power/Lock Key
• Powers device on/o
• Locks touch screen
• Turns display on/o
Menu Key
Directional Key
with Center Select
Back Key
• Returns you to previous
screen
Menu Key
• Opens application menu
Home Key
• Returns you to home
screen from any screen
Search Key
• Search the Web and device
content including Apps,
Contacts and Music
Charger Head
• Plugs into wall outlet
Charger/Data Cable
• Can be used for charging or
connecting to your PC
This end to micro-USB
port of device.
This end to
charger head.
Camera
Key
ALT Key
• To enter numbers
and symbols
Home Key:
Touch and hold to bring
up most recently used
applications.
Applications Tab
From the home screen, touch the Applications button
to open the Applications tab. Open an application
simply by touching it.
Enjoy the best of Google
applications such as Google
Maps, Gmail, Google Talk and
YouTube™.
Set an alarm.
Schedule a calendar event.
Send a text message.
Play music.
View or change your device settings such as call
ringtone, screen timeout, Wi-Fi, Bluetooth, location and
security management.
