SPECIFICATIONS
Motorola Limited, EMEA Headquarters
Jays Close, Viables Industrial Estate, Basingstoke, RG22 4PD, UK
Telephone: +44 (0)1256 358211
www.motorola.com
MOTOROLA and the Stylised M Logo are registered in the US Patent & Trademark Office.
All other product or service names are the property of their respective owners.
© Motorola, Inc. 2006. All rights reserved.
GP340-RE(08/06)
GENERAL SPECIFICATIONS
Channel Capacity 16
Power Supply Rechargeable Battery 7.5v
Dimensions: H x W x D (mm) Height excluding knobs
With Standard high capacity NiMH battery 137 x 57.5 x 37.5
With ultra high capacity NiMH battery 137 x 57.5 x 40.0
With NiCD battery 137 57.5 x 40.0
With Li-lon battery 137 x 57.5 x 33.0
Weight: (gm)
With Standard high capacity NiMH battery 420
With Ultra high capacity NiMH battery 500
With NiCD battery 450
With Li-lon battery 350
Average battery Life @5/5/90 Cycle: Low Power High Power
With Standard high capacity NiMH battery 11 hours 8 hours
With Ultra high capacity NiMH battery 14 hours 11 hours
With NiCD battery 12 hours 9 hours
With Li-lon 11 hours 8 hours
GENERAL SPECIFICATIONS (continued)
Sealing: Withstands rain testing per
MIL STD 810 C/D/E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL
STD 810-C/D/E and TIA/EIA 603
Dust and Humidity: Protection provided via environment
resistant housing exceeding
MIL STD 810 C/D/E and TIA/EIA 603
Operating temperature: -20°C to +55°C
Data is specified for +25°C unless otherwise stated.
PORTABLE MILITARY STANDARDS 810 C, D & E
810C 810D 810E
Applicable MIL-STD Methods Procedures Methods Procedures Methods Procedures
Low Pressure 500.1 1 500.2 2 500.3 2
High Temperature 500.1 1,2 501.2 1,2 501.3 1,2
Low Temperature 502.1 1 502.2 1,2 502.3 1,2
Temp. Shock 503.1 1 503.2 1 503.3 1
Solar Radiation 505.1 1 505.2 1 505.3 1
Rain 506.1 1,2 506.2 1,2 506.3 1,2
Humidity 507.1 2 507.2 2,3 507.3 2,3
Salt Fog 509.1 1 509.2 1 509.3 1
Dust 510.1 1 510.2 1 510.3 1
Vibration 514.2 8,10 514.3 1 514.4 1
Shock 516.2 1,2,5 516.3 1,4 516.4 1,4
TRANSMITTER
*Frequencies - Full Bandsplit VHF: 136-174 MHz LB1: 29.7-42 MHz
UHF: 300-350 MHz LB2: 35-50 MHz
UHF1: 403-470 MHz
Channel Spacing 12.5/20/25 kHz 12.5/20/25 kHz
Frequency Stability ±2.5 ppm ±10ppm
(-25°C to +55°C, + 25°C Ref.)
Power 136-174: 1-5W 1-6W
300-350: 1-4W
403-470: 1-4W
Modulation Limiting ±2.5 @ 12.5 kHz ±2.5 @ 12.5kHz
±4.0 @ 20 kHz ±4.0 @ 20 kHz
±5.0 @ 25 kHz ±5.0 @ 25 kHz
FM Hum & Noise -40dB typical -40dB typical
Conducted/Radiated Emission -36 dBm <1 GHz -36 dBm 1000MHz
-30 dBm >1GHz -30 dBm 1000MHz
Adjacent Channel Power -60 dB @ 12.5 kHz -60 dB @ 12.5 kHz
-70 dB @ 20/25 kHz -70 dB @ 25 kHz
Audio Response (300-3000Hz) +1 to -3 dB +1 to -3 dB
Audio Distortion 3% 3%
RECIEVER
*Frequencies - Full Bandsplit VHF: 136-174 MHz LB1: 29.7-42 MHz
UHF: 300-350 MHz LB2: 35-50 MHz
UHF1: 403-470 MHz
Channel Spacing 12.5/20/25 kHz 12.5/20/25 kHz
Sensitivity (12 dB SINAD) EIA .25µV typical .25µV typical
Sensitivity (20 dB SINAD) EN .50µV typical .50µV typical
Intermodulation EIA 70 dB 70 dB
Adjacent Channel Selectivity 60 dB @ 12.5 kHz 60 dB @ 12.5 kHz
70 dB @ 20/25 kHz 70 dB @ 25 kHz
Spurious Rejection 70 dB 70 dB
Rated Audio 0.5W 0.5W
Audio Distortion
@ Rated Audio 3% typical 3% typical
Hum & Noise -40 dB @ 12.5 kHz -45 @12.5 kHz
-50 @ 20/25 kHz -50 @ 20/25 kHz
Audio Response (300-3000 Hz) +1 to -3 dB +1 to -3dB
Conduncted Spurious Emission -57 dBm <1 GHz -57 dBm <1 GHz
-47 dBm <1 GHz -47 dBm <1 GHz
EN 300 086 FCC Part 15
*Availability subject to individual country’s law and regulations.
Specifications are subject to change without notice and are issued for guidance only.
All specifications listed are typical. Radios meet applicable regulatory requirements.
Conforms to EC directive 89/336/EEC
Complies with EN 300 113
