SPECIFICATIONS
MOTOROLA and the Stylised M Logo are registered in the US Patent & Trademark Office.
All other product or service names are the property of their respective owners.
© Motorola, Inc. 2006. All rights reserved.
GP344-RE(08/06)
GENERAL SPECIFICATIONS
Channel Capacity 16
Power Supply Rechargeable battery 7.5v
Dimensions: H x W x D (mm) Height excluding knobs
With standard Li-lon battery 101.5 x 55.5 x 30.5
With high capacity Li-lon battery 101.5 x 55.5 x35.5
Weight: (gm)
With standard Li-lon battery 250
With high capacity Li-lon battery 270
Average battery Life @5/5/90 Cycle: Low power High Power
With standard Li-lon battery >9 hours >7 hours
With high capacity Li-lon battery >13 hours >10 hours
Sealing: Withstands rain testing per MIL STD 810
C/D/E and IP54
Shock and Vibration: Protection provided via impact resistant
housing exceeding MIL STD 810-C/D/E and
TIA/EIA 603
Dust and Humidity: Protection provided via environment
resistant housing exceeding
MIL STD 810 C/D/E and TIA/EIA 603
Operating temperature: -20°C to +55°C
PORTABLE MILITARY STANDARDS 810 C, D & E
810C 810D 810E
Applicable MIL-STD Methods Procedures Methods Procedures Methods Procedures
Low Pressure 500.1 1 500.2 2 500.3 2
High Temperature 501.1 1,2 501.2 1,2 501.3 1,2
Low Temperature 502.1 1 502.2 1,2 502.3 1,2
Temp. Shock 503.1 1 503.2 1 503.3 1
Solar Radiation 505.1 1 505.2 1 505.3 1
Rain 506.1 1,2 506.2 1,2 506.3 1,2
Humidity 507.1 2 507.2 2,3 507.3 2,3
Salt Fog 509.1 1 509.2 1 509.3 1
Dust 510.1 1 510.2 1 510.3 1
Vibration 514.2 8,10 514.3 1 514.4 1
Shock 516.2 1,2,5 516.3 1,4 516.4 1,4
Data is specified for +25°C unless otherwise stated.
TRANSMITTER
*Frequencies - Full Bandsplit VHF: 136-174 MHz
UHF 1: 403-470MHz
UHF 2: 450-527 MHz
Channel Spacing 12.5/20/25 kHz
Frequency Stability ±2.5 ppm
(-25°C to +55°C, + 25°C Ref.)
Power 136-174: 1-5W
403-470: 1-4W
450-527: 1-4W
Modulation Limiting ±2.5 @ 12.5 kHz
±4.0 @ 20 kHz
±5.0 @ 25 kHZ
FM Hum & Noise -40 dB typical
Conducted/Radiated Emission -36 dBm <1 GHz
-30 dBm >1 GHz
Audio Response (300-3000Hz) +1 to -3 dB
Audio Distortion <5% typical
RECIEVER
*Frequencies - Full Bandsplit VHF: 136-174 MHz
UHF 1: 403-470 MHz
UHF 2: 450-527 MHz
Channel Spacing 12.5/20/25 kHz
Sensitivity (12 dB SINAD) EIA .35 µV typical
Intermodulation EIA -65 dB
Adjacent Channel Selectivity 60 dB @ 12.5 kHz
70 dB @ 20/25 kHz
Spurious Rejection 70 dB
Rated Audio 0.5W
Audio Response (300-3000 Hz) +1 to -3 dB
*Availability subject to individual country’s law and regulations.
Specifications are subject to change without notice and are issued for guidance only.
Radios meet applicable regulatory requirements.
Conforms to RTTE directives 1999/5/EC
Relevant standards: EN300 086-2, EN300 113-2, EN301 489-05
Contact your local Motorola Authorised Dealer to find out more about how communicating with the Professional Radio series will benefit your organisation.
