Item Function
• Vibrate mode — Sets the LEX L10 to vibrate only.
• Speaker on — Routes the earpiece sound to the
speaker.
Front Camera Used to capture live video for video calls.
Earpiece Provides audio in handset mode.
Secondary Microphone Use for making voice recordings and communications in
speakerphone mode.
Interface Connector Provides power to the LEX L10 from cradles.
Battery Cover Latch Assists in battery cover removal to provide access to the
battery, SIM, CRYPTR and microSD card holders.
Camera Button Starts the camera and takes photos and video.
microUSB Port Provides USB client and host communications.
Radio Paring Point Serves as a secure Bluetooth pairing point with Motorola
Solutions Land Mobile Radios (LMR).
Back Camera and Flash Takes photos and video, and provides flash illumination
for the camera.
2.2 Unpacking
Carefully remove all protective material from the LEX L10 and save the shipping container for later storage and
shipping. Verify that the following were received:
•
LEX L10
• Battery Cover
• 2280 mAh Lithium-ion battery
• USB Charger
• USB Cable
• Regulatory Guide
• Quick Start Guide
Inspect the equipment for damage. If any equipment is missing or damaged, contact the Motorola Solutions Support
Center immediately.
2.3 Setting Up the LEX L10
Note: The LEX L10 may be delivered to you with battery, SIM card, microSD card and/or CRYPTR cards
already installed, activated and ready for use. In this case, ignore steps 2 through 6 of the following section
if they were already performed.
Before using the LEX L10 for the first time, perform the following:
1 Remove the screen protection film from the LEX L10 screen. (See Removing the Screen Protective Film
on page
28).
2 Install the public and/or Private SIM cards. (See Installing the Public and Private SIM Cards on page 30).
Getting Started with the LEX L10 | 27
MN001456A01-A | February 2015 |
