Accessories 2 - 25
Figure 2-34
Single Bay USB Cradle with Clip
2. Align the Single Bay USB Cradle with the clip.
3. Snap the Single Bay USB Cradle onto the clip.
Figure 2-35
Single Bay USB Cradle and Battery Charger
Use the DC “Y” Cable to power both cradles.
1. Connect the power supply DC line cord to the female jack of the DC “Y” cable.
2. Connect one power plug of the DC “Y” cable to the power port on the Single Bay USB cradle and the other
power plug to the power port of the Single Slot Battery Charger.
