Motorola MCD 5000 User Manual

12
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used
under license. All other trademarks are the property of their respective owners.
© 2013 Motorola Solutions, Inc. All rights reserved.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used
under license. All other trademarks are the property of their respective owners.
© 2013 Motorola Solutions, Inc. All rights reserved.
MCD 5000 DESKSET
BOTTOM & SIDE VIEW
1 12V DC (A type connector) 9 HANDSET
2 INTERNAL LAN (RJ45) 10 MMI – RS-232 CONNECTION TO HYPER TERMINAL(RJ45)
3 EXTERNAL LAN-PoE (RJ45) 11 FOOTSTAND
4 FOOTSWITCH (3 PIN KK Molex connector) 12 PTT BUTTON
5 DESKMIC/HEADSET JACKBOX (RJ45) 13 FOOTSTAND RELEASE LATCH
6 LOGGER (RJ45) 14 CABLE HOLDER
7 RADIO COMM (RJ45) 15 HANDSET PORT (RJ22)
8 RADIO 4W E&M (RJ45) 16 VIP PORT

Motorola MCD 5000 Specifications

General

Brand	Motorola
Model	MCD 5000
Category	IP Phone
Language	English
