6-34 Circuit Board/Schematic Diagrams and Parts List for UHF
C8322_3 2113946U01
C8323_3 2113946U01
C8324_3 2113946U01
C8325_3 2113946U01
C8328_3 2113946U01
C8331_3 2113946U01
C8332_3 2113946U01
C105_2 21667009201
C102_2 21667009380
C8305_3 21667012146
C8335_3 21667013140
C107_2 2170282H06
C8334_3 CA000445A01
D0160 4871852M02
D0161 4871852M02
D0420 4813974A19
D3000 4805656W89
D4000 48009340001
D4101 4813974A19
E0001 91012036001
E0002 91012036001
E0003 91012036001
E0004 91012036001
E0005 91012036001
E0006 91012036001
E0007 91012036001
E0010 91012036001
E0012 91012036001
Circuit
Ref.
Motorola
Part No.
E0013 91012036001
E0014 91012036001
E0015 91012036001
E0016 91012036001
E0017 91012036001
E0018 91012036001
E0019 2471132D14
E0020 91012036001
E0021 2471132D14
E0023 91012036001
E0480 2471132D14
E0481 2471132D14
E0490 2471132D14
E0491 2471132D14
E0496 2471132D14
E0701 NOTPLACED
E0801 NOTPLACED
E0900 7686949J14
E1000 24012051001
E1001 24012051001
E1002 24012051001
E1003 24012051001
E1006 91012036001
E1007 91012036001
E1008 91012036001
E1009 91012036001
E1010 91012036001
E1020 24012065001
Circuit
Ref.
Motorola
Part No.
E3100 2471132D14
E3101 24012065001
E3102 24012065001
E3105 HZ000290A01
E3201 HZ000290A01
E3300 NOTPLACED
E3308 91013001001
E4000 24010078002
E4044 91012036001
E4045 91012036001
E4046 7688697V14
E4047 91012036001
E4100 24012178001
E4510 0613952R66
E4512 7688697V14
E4513 7688697V14
E4514 7688697V14
E4515 0613952R66
E4516 0613952K01
E4518 24009314031
E4519 24009314031
E4520 24009314031
E4521 24009314031
E4522 24009314031
E4523 24009314031
E4524 24009314031
E4525 24009314031
E8000 NOTPLACED
Circuit
Ref.
Motorola
Part No.
E8002 7686949J08
E8003 7688697V14
E8100 7686949J22
E8102 7688697V04
E8103 7688697V04
E105_2 7688697V14
E8300_3 7688697V14
F4020 65012019001
FL4100 2571601G01
FL8000 91012018002
FL8001 91012057001
FL8002 91012057001
J4100 09012192001
J4150 09012068001
J4200 CN000537A01
J4202 CN000225A01
J8000 CN000512A01
L0002 IN000122B19
L0003 24012146001
L0004 0613952G67
L0005 2488183V02
L0008 2471132D14
L0009 24012161001
L0014 24012161001
L0201 2475122C39
L0202 24009342012
L0203 24013081002
L0211 2475122C39
Circuit
Ref.
Motorola
Part No.
