3-2 Service Aids
2.0 Service Aids
Table 3-2 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Table 3-2 Service Aids
Motorola
Part Number
Description Application
RLN4460_ Test Box Enables connection to audio/accessory jack. Allows
switching for radio testing.
RVN5115_ Customer Programming
Software on CD-ROM
Allows servicer to program radio parameters, tune and
troubleshoot radios.
PMKN4010_ Mobile & Repeater Rear
Programming Cable
Connects the radio’s rear connector to a USB port for
radio programming and data applications.
PMKN4016_ Mobile & Repeater Rear
Accessory Programming and
Test Cable
Connects the radio’s rear connector to a USB port for
radio programming, data applications, testing and
alignment.
PMKN4018_ Mobile & Repeater Rear
Accessory Connector Universal
Cable
Connects the radio’s rear connector to accessory
devices such as desk sets. Cable contains all 26 wires
and is unterminated at the user end.
HKN6184_ Mobile Front Programming Cable Connects the radio’s front connector to a USB port for
radio programming and data applications.
HPN4007_ Power Supply Provides the radio with power when bench testing.
PMEN4027_ Housing Eliminator Test Fixture used to bench test the radio PCB.
6686119B01 Control Head Dismantling Tool Assists in the removal of radio control head.
66012025001 Volume/Channel Knob Removal
Tool
Assists in the removal of the Volume/Channel knob.
66012020001 RFIC (U0000) Repair Stencil Fixture to screen solder paste onto the IC leads for
replacement.
