6 - 14 MT2070/MT2090 User Guide

Video View Finder

Parameter # F0h, 44h

Select Enable Video View Finder to project the video view finder while in Video Mode, or Disable Video View

Finder to turn the video view finder off.

*Disable Video View Finder

(00h)

Enable Video View Finder

(01h)
