12 - 72 MT2070/MT2090 User Guide

QR Code

Parameter # F0h,25h

To enable or disable QR Code, scan the appropriate bar code below.

MicroQR

Parameter # F1h 3Dh

To enable or disable MicroQR, scan the appropriate bar code below.

*Enable QR Code

(01h)

Disable QR Code

(00h)

*Enable MicroQR

(01h)

Disable MicroQR

(00h)
