PPC Slave Address (0,1 and 2) Registers
To initiate a PCI cycle from the PPC bus, the PPC address must be greater
than or equal to the START field and less than or equal to the END field.
START Start Address. This field determines the start address of a
particular memory area on the PPC bus which will be used to access PCI
bus resources. The value of this field will be compared with the upper 16
bits of the incoming PPC address.
END End Address. This field determines the end address of a particular
memory area on the PPC bus which will be used to access PCI bus
resources. The value of this field will be compared with the upper 16 bits
of the incoming PPC address.
PPC Slave Address (3) Register
Address MSADD0 - $FEFF0040
MSADD1 - $FEFF0048
MSADD2 - $FEFF0050
Bit
0123456789
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
1
2
2
2
3
2
4
2
5
2
6
2
7
2
8
2
9
3
0
3
1
Name MSADDx
START END
Operation R/W R/W
Reset $0000 $0000
Address MSADD3 - $FEFF0058
Bit
0123456789
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
1
2
2
2
3
2
4
2
5
2
6
2
7
2
8
2
9
3
0
3
1
Name MSADD3
START END
Operation R/W R/W
Reset $8000 $8080
