RADIO OVERVIEW
English
26
Charging a Standalone Battery
To charge only the battery – at step 4, insert
the battery into the tray, with the inside surface
of the battery facing the front of the charger, as
shown. Ensure the slots in the battery correctly
engage in the charger
Note: Ensure that the bracket in the charger is
adjusted to the correct position for either
Standard or High capacity battery. See
“Charging a Standard Battery” on page 26
Charging a Standard Battery
The drop-in tray charger has a removable
bracket that is adjustable depending on the
type of battery that needs to be charged. It is
designed to charge either the battery (with the
radio) or a standalone battery. The drop-in tray
charger's default position will charge a
standard battery. The following image shows
the orientation for each battery:
Figure 1: Identifying the Drop-In Charger’s Position Before
Charging the Battery
djustable bracket
Standard
High and Ultra High Capacity
Adjustable bracket
BRUS_display.book Page 26 Monday, January 16, 2012 5:28 PM
