Test Procedures
MotorolaConfidential Proprietary
45
Set up for Analog call
Select CALL CTRLfrom the ANALOG
SCRNS Control panel
ï Select System type: AMPS
ïZero the RF Power meterin the: Call
Config Screen
ïSet Amplitude to:-50 dBm
ïSet SID: Your phoneís System ID
ïSelect: Active
ï Voice Channel Assignment Type:
ïChan: 212
ïPwr Lvl: 4
ï S A T :5970Hz
Registration
1. Put the Test Set in Active state by se-
lecting Active from the list on the left side of
the screen.
2. Select
Data
from the Data/Meas field.
This is the default mode.
3. Select Register from the list to regis-
ter phone.
4. If the registration message has been
received, the Test Set will display registration
data in the upper half of the screen as shown
in the sample screen above.
Page
1 Select page from the list on the left
side of the screen.
2 If the mobile responds, you will see
theAccess annunciator light briefly.
3 Answer the call by raising the flip or
press SEND on the mobile to start the con-
versation.
4 The Connect annunciator lights.This
is the Connect state.
Origination
1 Dial the desired phone number on the
mobile station and press SEND.
2 The Access annunciator will light while
the Test Set signalsthe mobile on the assigned
voice channel.
3 The connect annunciator will light if
the mobile properly signals the Test Set.
CALL CONTROL
Display
Active
Register
Page
Access
Connect
Order
MS Id
Active
Register
Page
Handoff
Release
Chng PL 0
Phone Num
1111111111
System Type
AMP
Cntrl Chan
334
Amplitude
-50.0
SID
231
To Screen
CA LL CNTL
CALL DATA
CA LL BIT
CALL CNFG
ANLG M EAS
SPEC ANL
AUTHE N
More
Data / Meas
dBm
Voice Channel Assisgnment
Chan : -
Pwr Lvl : -
SAT : -
Phone : 111-111-1111
ESN (dec) : 156-4460397
ESN (hex) : 9C440F6D
SCM : Class IV, Continuous, 25 MHz
212
4
5970Hz
