Motorola TLK 25 Wi-Fi - Wired Earpiece Overview; Attaching or Removing the Ear Tip; Attaching the Ear Tip

4.4
Wired Earpiece Overview
2
4
6
5
3
1
Table 6: Wired Earpiece Overview
Label Name Description
1 Microphone Allows your voice to be sent when PTT or voice operations
are activated.
2 Voice Assistant Button Allows you to access the voice assistant feature.
3 Push-to-Talk (PTT) But-
ton
Allows you to execute voice operations (for example,
Group Call and Private Call).
4 Mute/Unmute Toggle Allows you to toggle mute/unmute the device.
5 Earhook Allows you to hang the earpiece on your ear.
6 Removable Ear Tip Allows you to fit the earpiece to your ear.
4.5
Attaching or Removing the Ear Tip
Attaching the Ear Tip
Procedure:
Attach the ear tip to the earhook and twist clockwise until you hear a click.
MN009911A01-AA
Chapter
4 : Getting Started
19
