STEP 3: (Continued)

Step 3-2: Choose the appropriate position (three options) for your TV Plate, connecting TV Plate Unit to

Support Pillar(

②

) by using Bolts(D1) and Washers(D2). Use the 4mm allen key(J1) to tighten them.

55mm

②

TV Plate Unit

Note:

Three choices for

height adjustment.

Note: Arrow must be up!

Checklist

D1 (x4) Bolt M6×50mm

D2 (x4) D6 Washer

J1 (x1) 4mm Allen Key

No!
