6. Lower the deck to the ground in reverse order
after the corrective actions have been carried
out. Reset the deck according to “3”.
5.3 Service position
5.3.1 4000-series 4WD with fixed deck
connections and 2000-series
1. Activate the parking brake.
2. Set the maximum cutting height.
3. If the deck has electrical cutting height adjust-
ment, disconnect the cable from the machine.
See fig. 13.
4. See fig. 2. Detach the rear section of the deck on
the right and left-hand side as follows:
A. Lift up the left-hand rear section of the
deck slightly to reduce the load from the
cotter pin.
B. Remove pins and washer.
C. Remove the right-hand cotter pin and
washer in the same way.
5. Remove the belt cover (6:H) by loosening the
screws (6:I).
6. Loosen the belt guide screws (7, 8:K) a couple
of turns.
7. Release the belt tension as follows.
4000-series 4WD:
Grip the belt tensioner’s lever with your left
hand. Pull the lever and remove the tensioner
with your right hand. See fig. 9.
2000-series
:
Remove the tensioner from the belt. See fig. 11.
8. Force the belt off the deck’s pulley.
9. Grip the front edge of the deck and lift up. Lift
until the deck is completely vertical and rest the
rear edge on the ground. See fig. 20.
10.Lower the deck to the ground in reverse order
after the corrective actions have been carried
out. Reset the deck according to 3.1.
5.3.2 4000-series 2WD with fixed deck
connections
1. Activate the parking brake.
2. If the deck has electrical cutting height adjust-
ment, disconnect the cable from the machine.
See fig. 16.
3. Set the maximum cutting height.
4. See fig. 2. Detach the rear section of the deck on
the right and left-hand side as follows:
A. Lift up the left-hand rear section of the
deck slightly to reduce the load from the
cotter pin.
B. Remove pins and washer.
C. Remove the right-hand cotter pin and
washer in the same way.
5. Release the belt tension by removing the belt
tensioner. See fig. 10.
6. Force the belt off the machines’s pulley.
7. Grip the front edge of the deck and lift up. Lift
until the deck is completely vertical and rest the
rear edge on the ground. See fig. 20.
8. Lower the deck to the ground in reverse order
after the corrective actions have been carried
out. Reset the deck according to 3.2.
5.3.3 Machines with quick connections
1. Activate the parking brake.
2. If the deck has electrical cutting height adjust-
ment, disconnect the cable from the machine.
See fig. 16.
3. Set the maximum cutting height.
4. See fig. 2. Detach the rear section of the deck on
the right and left-hand side as follows:
A. Lift up the left-hand rear section of the
deck slightly to reduce the load from the
cotter pin.
B. Remove pins and washer.
C. Remove the right-hand cotter pin and
washer in the same way.
5. Set the quick connections in their rear positions.
See their supplied separate instruction.
6. Release the belt tension as follows.
4000-series 4WD:
Grip the belt tensioner’s lever with your left
hand. Pull the lever and remove the tensioner
with your right hand. See fig. 9.
4000-series
2WD:
Remove the tensioner from the belt. See fig. 10.
7. Force the belt off the deck’s pulley.
Check that the quick connections are in
their front positions before raising the
deck. Otherwise there is a risk of crush-
ing injuries.
8. Set the quick connections to their front posi-
tions, see separate instructions.
9. Grip the front edge of the deck and lift up. Lift
until the deck is completely vertical and rest the
rear edge on the ground. See fig. 20.
10.Lower the deck to the ground in reverse order
after the corrective actions have been carried
out. Reset the deck according to 3.3.
