COMPONENTES LIST
NAME
Chassis
A B C D
NAME
Connecting bar
NAME
Tower
NAME
Trinket Box
NAME
Lower support
E
F
G H
NAME
Higher support
NAME
Guide rod of
the fractionated
weight
NAME
Top Plate
NAME
Fractionated
weights
I
J
NAME
Weights
K
NAME
Selector pin
L
NAME
Steel cable
NAME
Steel cable
EDGE PLUS
M O
NAME
Rods
NAME
Support
N
P
NAME
Cam
R
NAME
Seat upholstery
NAME
Arm
Q1
NAME
S
NAME
Careen
T
U
NAME
Higher careen
14
Upholstery
TOOLS TABLE
Allen 5 mm
Allen 8 mm
Fix wrench 10 mm
Fix wrench 17 mm
Pliers for elastic ring
Philips wrench
Thread lock medium torque
Fix wrench 13 mm
Fix wrench 22 mm
Allen 4 mm
SPECIFICATION TABLE OF THE SCREW
TIGHT TORQUE
DIAMETER (mm) TORQUE (mm)
M6
TORQUE (mm)
M8
TORQUE (mm)
M10
TORQUE (mm)
M10X50
Scale 1:1 REFERENCE RULER Milimeters
NAME
Leg support
Q2
NAME
Leg upholstery
Q3
