STEP 8 - STEEL CABLE PASSAGE
22
ASSEMBLE
29
NAME Qty
Hex Nut Left Thread
M8
Hex Nut low profile
M8
37
NAME
Qty
Hex Head Screw
M10X60
2x
38
NAME Qty
Bush 4x
2
15
36
2x
10
Qty
Qty
Qty
Flate washer
M10
Hex Nut Insert Nylon
M10
Pulley
Qty
NAME
NAME
NAME
NAME
NAME
39
NAME Qty
Hex Head Screw
M6X50
3x
40
NAME Qty
Flat Washer
M6
6x
8
NAME Qty
Hex Nut Insert Nylon
M6
3x
Steel Cable
(Larger)
Steel Cable
(Smaller)
THE CORRECT ASSEMBLY POSITION
CABLE TENSIONER (15), IS
INDICATED THROUGH THE FRAME LOCATED
AT THE END. THE FRIEVE MUST
BEING UP
CABLES MUST BE ADJUSTED AS DESCRIBED IN
THIS MANUAL AND CHECKED DAILY SO THAT
DO NOT ESCAPE THE TENSIONER, AVOIDING
POSSIBLE ACCIDENTS WITH THE USER.
Qty
Maximum Distance 2,5 cm
Friese
Hex Nut low profile
Hex Nut left Thread
8
Ferramentas
Chave fixa 17 mm
Chave fixa 10 mm
L
M
3
NAME
NAME
Cable tensioner
Maximum Distance 2,5 cm
N
15
36
29
37
38
10
2
2
3
39
40
40
40
40
8
1
2 3
4
5 6
F
2x
To Next Page
