GETTING TO KNOW THE EQUIPMENT
12
CAUTION!
Before starting to assemble the equipment, the following precautions must be taken:
•
Make sure that the packaging is not damaged and that the parts and components of the equipment are not damaged.
•
It is recommended that the equipment be unpacked where it will be assembled.
•
The assembly location must be clean.
•
The #oor must be #at and level to avoid equipment instability.
•
The space around the equipment must be free, as described in this Manual.
•
It is recommended that the equipment be mounted away from moisture and out of sunlight to avoid damage to
the electronic parts of the equipment.
50%
Do not apply
the !nal
tightening on
the screws
100%
Apply the !nal
tightening to
the screws
Two people are
recommended
to perform the
assembly
ICONS
The icons are intended to instruct good
practices that must be followed during
assembly.
Allen n° 6
Allen n° 8
Allen n° 10
Philips
screwdr
iver
SCREW TIGHTENING TORQUE
SPECIFICATION TABLE
TOOLS
Use the following tools to assemble the
equipment. The torque tableis intended to
guide how much tightening a given screw
can undergo. The table must be strictly
followed.
SPACE
We indicate, for the user's safety, the use of a minimum access and escape area, as
shown in the picture beside. The access and escape area can be common among the
equipment used.
60 cm
60 cm
2 m
60 cm
AIR BIKE
Fixed
wrench
17
