ioLogik E1200 Series Modbus/TCP Default Address Mappings
2: Over Range
3. Under Range
Read AI 3 Current Mode Status
0: Normal
1: Burn Out
2: Over Range
3. Under Range
4xxxx Read/Write Registers (Functions 3, 6, 16)
DO all Value (Ch0–3)
Bit0 = Ch0 DO Value (0=OFF, 1=ON)
Bit3 = Ch3 DO Value (0=OFF, 1=ON)
Bit4 to 15 = reserved
CH0 AI 0 Mode: 1:4-20mA, 2:0-20mA, 4:BO
CH0 AI 1 Mode: 1:4-20mA, 2:0-20mA, 4:BO
CH0 AI 2 Mode: 1:4-20mA, 2:0-20mA, 4:BO
CH0 AI 3 Mode: 1:4-20mA, 2:0-20mA, 4:BO
CH AI 0 BO Value (floating point)
CH AI 1 BO Value (floating point)
CH AI 2 BO Value (floating point)
CH AI 3 BO Value (floating point)
E1260 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
3xxxx Read Only Registers (Function 4)
CH0 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
CH1 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
CH2 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
CH3 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
CH4 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
CH5 Read RTD Value
Range 0–65535, Unit:0.1 (Ohm, Celsius, Fahrenheit)
