3 Insert the automatic cleaning module (10) onto the juicer extracting strainer (9).
4
Insert and adjust the stainless steel strainer (9) with the automatic cleaning module (10) in the
container (5) so that the projection on the strainer is inserted in the container groove (5) and
markings on the strainer (9) and container (5) face each other.
5 Insert the snail extruder (8) into the extrusion sieve (9).
OPEN
OPEN
CLOSE
CLOSE
6
Place the cover (6) on the container (5) inserting the projections in the grooves located in the bowl
and turn the cover (6) clockwise home so that the protective projection in the cover (6) fits in the
recess in the workstation (1) (confirmed by an audible click).
Mind the markings on the device. In this way you remove the protection against operation the
appliance if improperly assembled.
7 Place the tray (15) on the cover (6). Place the container (4) under the juice (12) and waste outlet (13).
