mr.Kate 5211849COM - Step 3: Connecting Panels with Cam Locks

C
C
× 4
Ø15X 12mm
3
× 4
4
Proper orientation of CAM LOCK
3.1 Attach (C) to (D) with (3) as illustrated.
3.2 Use (4) to cover cam lock hole.
3
4
