Note: Adjust wheelchair so that it is centered on the trolley before locking the wheel support knob. Wheelchair
should be all the way back, with trolley frame centered between the wheelchair push handles.
Note: The red wheel supports are depth adjustable. If the back of the chair is not touching the trolleys frame, you
can adjust the depth of the support to accommodate your specific wheel size. There are 2 bolts on each support.
4. Lock wheel supports into place by pulling red knob out
and down.
5. Next, you will need to adjust locking side supports to
lock your wheelchair onto trolley.
6. Secure the wheelchair into place with red wheelchair
frame locking supports located on each side of the
trolley.
7. To adjust width of the locking supports, pull out on
black knob located on each side support. Slide the
locking side supports in or out to the necessary
position.
8. Lock the side supports by releasing black knob.
NOTE: Locking side supports should grab wheelchairs back
frame uprights, either above or below the armrests. Some
armrests may need to be removed to secure wheelchair
to trolley.
Note: If the side supports need to be height adjusted to
accommodate the chairs arm rests, you can adjust
them with the black knobs located on the front side of the
trolleys frame. Unscrew knobs on both sides,
slide the supports to the desired height and lock both knobs.
Preparing for passenger loading:
1. Roll wheelchair evacuation trolley next to patient, once
chair is in position, LOCK rear casters.
2. To lock rear casters, push down red lever located on top of rear wheels.
3. Make sure locks are engaged by trying to move chair.
4. If chair does not move, you are ready to seat and secure your passenger.
Loading your Passenger:
1. Assist your passenger into seat using wheelchairs handlebars for support and balance if necessary.
2. Secure your passenger with horizontal lap belts (if provided)
Patient Transport Descending: cont’d next page
