MSA SMC 5100-IT Series User Manual

5.3 Main Menu
Function Display Description Reference
Mode Switch [M]
Enter Switch [E]
Up Switch [▲] Previous Menu
Down Switch [▼] Next Menu
5100-XX First screen at power up: Model No.
VXX-XX-- Second screen at power up: Version No.
STARTING
Third screen at start up, will remain for 60
seconds
XXX PPM Normal condition - default display
Mode ALMRSET: Mode Function - Alarm Reset
Banner: "Press [E] to reset alarm"
RESET Alarm Reset
XXX PPM Default Display
Mode ALMRSET: Mode Function - Alarm Reset
Mode CALIB: Mode Function - Calibrate
Section 6.3 Calibration Gas Delivery
Methods
Mode SETUP: Mode Function - Set up alarms, relays, etc. Section 5.4 Set-Up
Mode MAINT: Mode Function – Maintenance Section 5.5 Maintenance Sub-Menu
Mode EXIT-? Exit Mode
Enter XXX PPM Apply Selected Mode (Exit)
XXX PPM Default Display (Once a minute the sensor displays module address)
