The table below defines the key operational displays on the operator interface.

Display Description

STARTING Delay from loss of power at start-up

XXX PPM Concentration

LXXX PPM Low Alarm (Warning)

HXXX PPM High Alarm (Alarm)

HIGH Measures gas, concentration exceeds 100% of Full Scale

CXXX PPM Calibration Mode

ACK Acknowledged Function

NOTE:If display shows “Start” instead of “Starting”, the module must be calibrated before using it.

26 SMC 5100-XX-IT Toxic Gas Detector Module

5 Operation US
