7.6.10Error Messages
LED Display
(Ver 3.05 and earlier)
LED Display
(Ver 3.07 & later)
Description
NO SENSR NO SENSR Unable to detect sensor assembly
Err: 0x02 DIG INP! Digital Input status
Err: 0x20 SNS RNGE Sensor ADC readings out of range
Err: 0x40 SNS FAIL Too many 1-wire communication errors
Err: 0x80 NO SENSR Faulty 1-wire initialization - too few devices
Err: 100 SNS TYPE Sensor Initialization Error (no Type)
Err: 200 SNS TBL Forced Trouble (Test Condition)
Err: 400 SNS LOW Very low sensor output - down indicator
Err: 800 SNS LOW Very low sensor output (<5% for Oxygen sensor)
COM SNSR SNS FAIL Internal sensor communication error
SMC 5100-XX-IT Toxic Gas Detector Module 39
US 7 Service
