MSA Ultima X Series Instruction Manual

NOTES:
• Incoming power and signal cable shield should be earth
grounded at the power source. Connect power and
remote sensor cable shields to shield terminals on main
pc board. Provide shield terminations inside the sensor
housing as indicated on Installation Outline Drawings for
Remote Sensor; see Table 3-1 for Installation Outline
Drawing document numbers.
• Cables larger than #16 AWG will require a splice of
smaller cable to fit the connector.
Chapter 1, Installation
1-14

MSA Ultima X Series Specifications

General

Brand	MSA
Model	Ultima X Series
Category	Measuring Instruments
Language	English
