IN STALL AT IO N INS TR UCTIONS 7
M S D I G N I T I O N • w w w. ms d ig ni ti o n. co m • ( 91 5) 8 5 7- 52 00 • FAX ( 91 5 ) 85 7- 3 34 4
DEFAULT SETTINGS AND ADJUSTMENTS
The following list shows all of the default values and adjustable increment of the PN 7530 Ignition.
Display Default Data Low-High (step by)
ShiftLt1 ###00 Rpm 12,500 2,000-12,500 (100)
ShiftLt2 ###00 Rpm 12,300 2,000-12,500 (100)
ShiftLt3 ###00 Rpm 12,100 2,000-12,500 (100)
ShiftLt4 ###00 Rpm 11,900 2,000-12,500 (100)
ShiftLt5 ###00 Rpm 11,700 2,000-12,500 (100)
LastGear # 5 2-6
MagComp #.# Deg 2.0 0-3.0 (.5)
RevBurn ###00 Rpm 7,000 2,000-12,500 (100)
RevLaunch ###00 Rpm 6,200 2,000-12,500 (100)
RevMax ###00 Rpm 9,500 2,000-12,500 (100)
RetStart ## Deg 10 00-25
Retard1 ##.# Deg 2.0 0-15.0 (.5)
Retard2 ##.# Deg 3.0 0-15.0 (.5)
Retard3 ##.# Deg 5.0 0-15.0 (.5)
Retard1 ###00 Rpm 800 800-12,500 (100)
Retard2 ###00 Rpm 800 800-12,500 (100)
Retard3 ###00 Rpm 800 800-12,500 (100)
RetLaun ##.# Deg 0.0 0-15.0 (.5)
RampTim #.## Sec .50 0-2.50 (.01)
Spark1 #.# Deg 0 0-5.0 (.1)
Spark2 #.# Deg 0 0-5.0 (.1)
Spark3 #.# Deg 0 0-5.0 (.1)
Spark4 #.# Deg 0 0-5.0 (.1)
Spark5 #.# Deg 0 0-5.0 (.1)
Spark6 #.# Deg 0 0-5.0 (.1)
Spark7 #.# Deg 0 0-5.0 (.1)
Spark8 #.# Deg 0 0-5.0 (.1)
CylCnt $ 8 4/6/8
Distributor Distributor Distributor/CrankTrigger
DropRpm ##00 600 500-1500 (100)
RunCurve Rpm ###00 800 800-12500 (100)
RunCurve Deg ##.# 0 0.0-25.0 (.1)
LaunchCurve Rpm ###00 800 800-12500 (100)
LaunchCurve Deg ##.# 0 0.0-25.0 (.1)
StepOffDelay #.## .50 0-2.50 (.01)
AlertsPer # 0 0-1
RpmSw On 2000 2000-12,500 (100)
RpmSw Off 6000 2000-12,500 (100)
Gear3 Retard Deg #.# 0 0.0-5.0 (.5)
Gear4 Retard Deg #.# 0 0.0-5.0 (.5)
Gear5 Retard Deg #.# 0 0.0-5.0 (.5)
Gear6 Retard Deg #.# 0 0.0-5.0 (.5)
ScanTime #Sec 1 1-9
CamSync $$$$ NONE/SYNC
Rpm #### monitor
RetSum ##.# monitor
ShiftLt $$ OFF/ON
LowBatt $$$ OK/LOW
Gear # 1-5
RpmSw $$$ OFF/ON
MaxCylDeg 0.0-5.0
TrigScr NONE/MAG/PTS
Step1In OFF/ON
Step2In OFF/ON
Step3In OFF/ON
RevLaunIn OFF/ON
RevBurnIn OFF/ON
