Specifications
Continued from previous page
Internal Connectors
y 1x 24-pin ATX main power connector
y 1x 8-pin ATX 12V power connector
y 6x SATA 6Gb/s connectors
y 3x USB 2.0 connectors (supports additional 6 USB 2.0
ports)
y 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1
Gen1 ports)
y 1x 4-pin CPU fan connector
y 2x 4-pin system fan connectors
y 1x 3-pin system fan connector
y 1x Front panel audio connector
y 2x Front panel connectors
y 1x TPM module connector
y 1x Chassis Intrusion connector
y 1x Serial port connector
y 1x Clear CMOS jumper
I/O Controller FINTEK F71889ED Controller Chip
Form Factor
y ATX Form Factor
y 12 in. x 8.9 in. (30.5 cm x 22.5 cm)
Software
y Drivers
y COMMAND CENTER
y LIVE UPDATE 6
y NETWORK GENIE
y FAST BOOT
y SUPER CHARGER
y Norton
™
Security
y Google Chrome
™
,Google Toolbar, Google Drive
