14
Internal
Connectors
1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
8x SATA 6Gb/s connectors (A88XM-E45 V2)
6x SATA 6Gb/s connectors (A78M-E45 V2)
6x SATA 3Gb/s connectors (A55M-E45 V2)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
(A88XM-E45 V2/ A78M-E45 V2)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x 3-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
1x Parallel port connector
1x Clear CMOS jumper
BIOS
Features
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
Form Factor Micro-ATX Form Factor
9.6 in. x 9.6 in. (24.3 cm x 24.3 cm)
For the latest information about CPU, please visit
http://www.msi.com/cpu-support/
For more information on compatible components, please visit
http://www.msi.com/test-report/
