MSI A68HM-P33 Series - Motherboard Internal Headers; BIOS Functionality; Physical Specifications

English
13
Internal
Connectors
󰀲 1x 24-pin ATX main power connector
󰀲 1x 4-pin ATX 12V power connector
󰀲 4x SATA 6Gb/s connectors
󰀲 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
󰀲 1x 4-pin CPU fan connector
󰀲 2x 4-pin system fan connectors
󰀲 1x Front panel audio connector
󰀲 2x System panel connectors
󰀲 1x Chassis Intrusion connector
󰀲 1x TPM module connector
󰀲 1x Serial port connector
󰀲 1x Parallel port connector
󰀲 1x Clear CMOS jumper
BIOS
Features
󰀲 󰘱
󰀲 UEFI AMI BIOS
󰀲 ACPI 5.0, PnP 1.0a, SM BIOS 2.8, DMI 2.8
󰀲 Multi-language
Form Factor 󰀲 Micro-ATX Form Factor
󰀲 24.4 cm x 17.4 cm
For the latest information about CPU, please visit http://www.
msi.com/cpu-support/
For more information on compatible components, please
visit http://www.msi.com/test-report/
