8
Connecting the Front Panel Header
HDD LED
RESET SW
http://youtu.be/DPELIdVNZUI
JFP1
HDD LED
HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED
1
2 10
9
Power LED
Reserved
Power Switch
JFP1
Reset SwitchHDD LED

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI B450M-A PRO MAX II and is the answer not in the manual?

MSI B450M-A PRO MAX II Specifications

General IconGeneral
Form FactorMicro-ATX
ChipsetAMD B450
CPU SocketAM4
Memory Slots2
Maximum Memory64 GB
Memory TypeDDR4
PCIe Slots1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
Storage Interface4 x SATA 6Gb/s, 1 x M.2
USB Ports6 x USB 3.2 Gen1, 6 x USB 2.0
LANRealtek RTL8111H Gigabit LAN
AudioRealtek ALC892/ALC897
