CX623（MS-168A）Disassemble Guide

6、SEPARATE UPPER CASE AND LOWER CASE

6.6：Remove the 2 screws (M2*3mm) that stabilize

the hinge Cap.

Attention: the screw driver torque is 1.2-1.5Kgf-cm

Component P/N Qty

Screw E43-1203003-G68 2

6.7 ： Remove the 4 screws(M2.5*5mm) that

stabilize the hinge

Attention: the screw driver torque is 3.0-3.5Kgf-cm

Component P/N Qty

Screw E43-1255001-G68 4
