MSI G255PF E2 User Manual

5
G255PF E2
1. Leave the monitor in its protective packaging. Align the stand bracket to the
monitor groove.
2. Tighten the stand bracket with screws.
3. Connect the base to the stand and tighten the base screw to secure the base.
4. Make sure the stand assembly is properly installed before setting the monitor
upright.
11
22
33
⚠
Important
The back of the monitor can also be used for wall mount. Please contact your dealer
for proper wall mount kit.

MSI G255PF E2 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.2832 x 0.2802 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	24.5 \
Anti-glare screen	Yes
Display technology	LCD
Vertical scan range	48 - 180 Hz
Maximum refresh rate	180 Hz
Horizontal scan range	52.7 - 198 kHz
Viewable size, vertical	302.616 mm
Contrast ratio (dynamic)	100000000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	543.744 mm
Display brightness (typical)	300 cd/m²
Headphone outputs	1
DisplayPort version	1.2a
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (standby)	- W
Package type	Box
Package weight	7800 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Product color	Black
Market positioning	Gaming
Storage temperature (T-T)	-30 - 30 °C
Operating temperature (T-T)	-5 - 20 °C
Storage relative humidity (H-H)	-90 - 90 %
Operating relative humidity (H-H)	0 - 130 %

Weight and Dimensions

Depth (with stand)	227.9 mm
Width (with stand)	557.1 mm
Height (with stand)	381.9 mm
Weight (with stand)	5300 g
Depth (without stand)	66.4 mm
Height (without stand)	326.9 mm
Weight (without stand)	2870 g
