MSI G273CQ - Page 10

10
Getting Started
1
Power LED
Lit in white after the monitor is turned on. If no signal input, the LED will
turn into orange. Lit in orange when the monitor is in Stand-by mode.
2
Power Button & Navi Key
3
Kensington Lock
4
Power Jack
5
HDMI Port
6
DisplayPort
7
Headphone Jack
8
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 5V/3A
(15W) power delivery.
9
USB 2.0 Type-B Upstream Port
For USB Upstream Cable.
⚠
Important
Check the package for USB Upstream Cable
and connect it to the PC and monitor. Once
this cable is connected, the USB Type-A
Downstream Ports on the monitor will be
ready for use.
To PC
To Monitor
10
USB 2.0 Type-A Port
