10
Getting Started
1
Macro Key
To activate OSD Application.
2
Power Button
3
Navi Key
4
Kensington Lock
5
Cable Routing Hole
6
DisplayPort
Supports 2560x1440@170Hz as specified in DisplayPort 1.2a.
7
HDMI™ Connector
Supports HDMI™ CEC, 2560x1440@144Hz as specified in HDMI™ 2.0b.
8
HDMI™ Connector
Supports 2560x1440@144Hz as specified in HDMI™ 2.0b.
9
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 5V/3A
(15W) power delivery.
10
Headphone Jack
11
USB 2.0 Type-B Upstream Port
For USB Upstream Cable.
⚠
Important
Check the package for USB Upstream Cable
and connect it to the PC and monitor. Once
this cable is connected, the USB Type-A
Downstream Ports on the monitor will be
ready for use.
To PC
To Monitor
12
USB 2.0 Type-A Port
13
Power Jack
To Next Page
