5. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
6. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
7. USB 3.2 Gen 1/ Gen 2 Port (optional)
USB 3.2 Gen 1/ Gen 2, the SuperSpeed USB/ SuperSpeed USB 10Gbps, delivers
the higher interface speeds for connecting various devices, such as storage devices,
hard drives, or video cameras, and offers more advantages over high-speed data
transferring.
8. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported.
Microphone
• Used for an external microphone.
• Connect the Center and woofer speakers here.
Headphone out/ S/PDIF-out/ HiFi Audio output
• A connector for speakers or headphones.
• Connect the Front speakers here.
• The S/PDIF connector is also provided for digital audio
transmission to external speakers through an optical fiber
cable.
• HiFi audio output is supported through this connector.
