7
1
Power LED
Lit in white after the monitor is turned on. If no signal input, the LED will
turn into orange. Lit in orange when the monitor is in Stand-by mode.
2
Cable Routing Hole
3
Power Button & Navi Key
4
Power Jack
5
Headphone Jack
6
HDMI™ Connector
Supports HDMI™ CEC, 3840x2160@160Hz as specified in HDMI™ 2.1.
7
HDMI™ Connector
Supports 3840x2160@160Hz as specified in HDMI™ 2.1.
8
DisplayPort
Supports 3840x2160@160Hz as specified in DisplayPort 1.4a.
9
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 5V/3A
(15W) power delivery. It only carries video signals and doesn’t support data
transmission function.
⚠
Important
Your USB-C signal source and cable must support DisplayPort Alternate
Mode to enable video output to the monitor.
