Specifications
Continued from previous page
Storage
 4x SATA 6Gb/s ports (SATA5~8, from B660 Chipset)*
 2x SATA 6Gb/s ports (SATA_A & SATA_B, from ASMedia
ASM1061)
 2x M.2 slots (Key M)
 M2_1 slot (From CPU)
 Supports PCIe 4.0 x4
 Supports 2242/ 2260/ 2280 storage devices
 M2_2 slot (From B660 Chipset)*
 Supports PCIe 4.0 x4
 Supports SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
 Supports Intel® Optane™ Memory
* SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
RAID
 Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices*
* SATA_A & SATA_B do not support RAID function.

Intel® B660 Chipset
 
panel
 
through the internal connector
 2x USB 3.2 Gen 1 5Gbps ports available through the
internal connector
 4x USB 2.0 ports on the back panel
 
 
panel
 
 4x USB 2.0 ports available through internal connectors
Audio
Realtek® ALC1200 Codec
 
 Supports S/PDIF output
LAN 1x Realtek® 8125BG 2.5Gbps LAN controller
Continued on next page

MSI MAG B660M MORTAR WIFI DDR4 Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 4000, 4200, 4400, 4600, 4800 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Parallel processing technology support	Crossfire
USB 2.0 connectors	2
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel B660
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	-
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Width	244 mm
Height	65 mm
