20
Specifications
Continued from previous column
Back Panel
Connectors
∙ 1x DisplayPort
∙ 1x HDMI port
∙ 1x Flash BIOS button
∙ 2x USB 2.0 Type-A ports
∙ 4x USB 3.2 Gen1 5Gbps Type-A ports
∙ 1x LAN I225V port
∙ 1x LAN I219V port (For MAG Z590 TORPEDO only)
∙ 1x USB 3.2 Gen 2 10Gbps Type-A port
∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port
∙ 2x Wi-Fi Antenna connectors (For MAG Z590 TOMAHAWK
WIFI only)
∙ 5x Audio jacks
∙ 1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687-R Controller Chip
Hardware Monitor
∙ CPU/ System/ Chipset temperature detection
∙ CPU/ System/ Pump fan speed detection
∙ CPU/ System/ Pump fan speed control
Form Factor
∙ ATX Form Factor
∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
BIOS Features
∙ 1x 256 Mb flash
∙ UEFI AMI BIOS
∙ ACPI 6.2, SMBIOS 3.0
∙ Multi-language
