Continued from previous column
Internal USB
Connectors
AMD® B650 Chipset
∙ 1x USB 3.2 Gen 2 10Gbps Type-C connector
∙ 1x USB 3.2 Gen 1 5Gbps connector
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
∙ 2x USB 2.0 connectors
• Supports additional 4 USB 2.0 ports
Fan Connectors
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 6x 4-pin System fan connectors
System Connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x TPM module connector
∙ 1x Tuning Controller connector
Jumpers ∙ 1x Clear CMOS jumper
LED Features
∙ 1x EZ LED Control switch
∙ 2x 4-pin RGB LED connector
∙ 2x 3-pin ARGB_V2 LED connectors
∙ 4x EZ Debug LED
Back Panel
Connectors
∙ 1x Flash BIOS button
∙ 1x DisplayPort
∙ 1x HDMI™ port
∙ 3x USB 3.2 Gen 2 10Gbps Type-A ports (From CPU)
∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B650
chipset)
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports (From B650
chipset)
∙ 2x USB 2.0 Type-A ports (From B650 chipset)
∙ 1x LAN (RJ45) jack
∙ 2x Wi-Fi Antenna connectors
∙ 5x audio jacks
∙ 1x Optical S/PDIF Out connector
Continued on next column
