18
Continued from previous column
Audio
∙ Realtek® ALC897 Codec
• 7.1-Channel High Definition Audio
LAN ∙ 1x Realtek® 8125B 2.5Gbps LAN controller
Power Connectors
∙ 1x 24-pin ATX main power connector
∙ 1x 8-pin +12V power connector
Internal USB
Connectors
∙ 1x USB 3.2 Gen 1 5Gbps connector (From A620/ B650
chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
∙ 2x USB 2.0 Type-A connectors (From A620/ B650 chipset)
• Supports additional 4 USB 2.0 ports
Fan Connectors
∙ 1x 4-pin CPU fan connector
∙ 2x 4-pin system fan connectors
System Connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis intrusion connector
∙ 1x TPM module connector
∙ 1x Serial port connector
Jumpers
∙ 1x Clear CMOS jumper
∙ 1x OC safe boot jumper
LED Features
∙ 1x 4-pin RGB LED connector
∙ 1x 3-pin ARGB Gen2 LED connector
∙ 4x EZ Debug LED
Continued on next column
