6
Continued from previous page
Fan Connectors
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
5x 4-pin system fan connectors
System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Tuning controller connector
1x TBT connector (Supports RTD3)
Jumpers 1x Clear CMOS jumper
LED Features
1x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
4x EZ Debug LED
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
4x USB 2.0 Type-A ports (From B660 chipset)
1x VGA port
1x DisplayPort port
1x HDMI port
1x LAN (RJ45) port
2x USB 3.2 Gen 2 10Gbps Type-A port (From B660 chipset)
1x USB 3.2 Gen 2 10Gbps Type-C port (From B660 chipset)
5x Audio jacks
1x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687-R Controller Chip
Hardware Monitor
CPU core/ System/ Chipset/ MOS/ CPU socket
temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Continued on next page
