MSI PRO B660M-A WIFI DDR4 User Manual

6
Fortsetzung der vorherigen Spalte
Interne USB
Anschlüsse
 1x USB 3.2 Gen 1 5Gbit/s Typ-C Anschluss (vom B660
Chipsatz)
 1x USB 3.2 Gen 1 5Gbit/s Typ-A Anschluss (von ASM1074)
• Unterstützt zusätzliche 2 USB 3.2 Gen 1 5Gbit/s
Anschlüsse
 2x USB 2.0 Typ-A Anschlüsse (vom B660 Chipsatz)
• Unterstützt zusätzliche 4 USB 2.0 Anschlüsse
Stromanschlüsse
für Lüfter
 1x 4-poliger CPU-Lüfter-Stromanschluss
 1x 4-poliger Anschluss für die Wasserpumpe
 2x 4-polige System-Lüfter-Anschlüsse
Systemanschlüsse
 1x Audioanschluss des Frontpanels
 2x System-Panel-Anschlüsse
 1x Gehäusekontaktschalter
 1x TPM Anschluss
 1x Tuning Controller-Anschluss
 1x TBT Anschluss (Unterstützt RTD3)
 1x Serielle Schnittstelle
Steckbrücke  1x Clear CMOS Steckbrücke
LED Funktionen
 1x 4-poliger RGB LED Anschluss
 2x 3-polige RAINBOW LED Anschlüsse
 4x EZ Debug LED
Hintere Ein-/ und
Ausgänge
 1x PS/2 Maus/Tastatur-Anschluss
 2x USB 2.0 Typ-A Anschlüsse (vom B660 Chipsatz)
 2x DisplayPort Anschlüsse
 2x HDMI Anschlüsse
 2x USB 3.2 Gen 1 5Gbit/s Typ-A Anschluss (von B660
Chipsatz)
 2x USB 3.2 Gen 2 5Gbit/s Typ-A Anschluss (von B660
Chipsatz)
 1x 2,5Gbit/s LAN (RJ45) Anschluss
 2x Wi-Fi-Antennenanschlüsse (PRO B660M-A WIFI DDR4)
 3x Audiobuchsen
Fortsetzung auf der nächsten Spalte

MSI PRO B660M-A WIFI DDR4 Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i9
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 4000, 4200, 4266, 4400, 4600, 4800 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	SSD
Supported storage drive interfaces	M.2, SATA III
DirectX version	12.0
Parallel processing technology support	Not supported
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B660
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 11
BIOS type	EFI AMI
System Management BIOS (SMBIOS) version	3.2
Cables included	SATA
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Width	244 mm
Height	86 mm
