MSI PRO B660M-P WIFI DDR4 User Manual

5
Continued from previous column
M.2 SSD Slot
 1x M.2 slot (Key M)
• M2_1 slot (From B660 Chipset)
• Supports up to PCIe 4.0 x4
• Supports 2242/ 2260/ 2280 storage devices
* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Audio
Realtek® ALC897 Codec
 7.1-Channel High Definition Audio
LAN 1x Realtek® RTL8111H 1Gbps LAN controller
Wi-Fi & Bluetooth®
(PRO B660M-P WIFI
DDR4)
Intel® Dual Band Wireless-AC 3168
 Dual Band 1x1 802.11ac
 2.4GHz/ 5GHz bands
 433 Mbps Max Speed
 Bluetooth 4.2 (BR/EDR, BLE)
 Supports Windows 7/ 8.1/ 10
Power Connectors
 1x 24-pin ATX main power connector
 1x 8-pin ATX 12V power connector
Internal USB
Connectors
 1x USB 3.2 Gen 1 5Gbps Type-C connector (From B660
chipset)
 1x USB 3.2 Gen 1 5Gbps Type-A connector (From B660
chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 1x USB 2.0 Type-A connector (From B660 chipset)
• Supports additional 2 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin system fan connector
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
 1x parallel port connector
 1x Serial port
Continued on next column
Downloaded from ManualsNet.com search engine

MSI PRO B660M-P WIFI DDR4 Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i9
Supported processor sockets	LGA 1700
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3200, 3333, 3400, 3466, 3600, 3733, 3800, 4000, 4200, 4266, 4400, 4600 MHz
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
RAID levels	0, 1, 5, 10
Supported storage drive types	SSD
Supported storage drive interfaces	M.2, SATA III
DirectX version	12.0
Parallel processing technology support	Not supported
BIOS type	-
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B660
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 11

Weight and Dimensions

Width	244 mm
