MSR6 05 Programmer ’ s Manual Rev. A
15
Section
Section
Section
Section 9
9
9
9 Addendum
Addendum
Addendum
Addendum
� Write
Write
Write
Write Data
Data
Data
Data to
to
to
to Magnetic
Magnetic
Magnetic
Magnetic Card
Card
Card
Card
The
The
The
The WRITE
WRITE
WRITE
WRITE command
command
command
command :
[
[
[
[ Data
Data
Data
Data Block
Block
Block
Block ]
]
]
] format:
format:
format:
format:
[
[
[
[ card
card
card
card data
data
data
data ]
]
]
] format:
format:
format:
format:
As an example the following information will be written to the card:
Track1: %ABC123?
Track2: ;12345?
Track3: ;12345?
Command
WRITE
Command code
<ESC> w [Data
[Data
[Data
[Data Block]
Block]
Block]
Block]
Hex code
1B 77 [Data
[Data
[Data
[Data Block]
Block]
Block]
Block]
Response
<ESC> [Status Byte]
Description
This command request MSR605 to write the Data Block into the card swiped.
Start Field
R/W Data Field
Ending Field
Command code
<ESC>s
[ card data ]
?<FS>
HEX code
1B 73
[ card data ]
3F 1C
card data
Char. code
<ESC>[01] [string] <ESC> [02] [string] <ESC> [03] [string3]
HEX code
1B 01 [string1] 1B 02 [string2] 1B 03 [string3]
HOST
DIRECTION
MSR605
Command code:
<esc>w<ESC>s<ESC>[01]ABC123<ESC>
[02]12345<ESC>[03]12345?<FS>
HEX code:
[1B][77][1B][73][1B][01][41][42][43][31][
32][33][1B][02][31][32][33][34][35][1B][0
3][31][32][33][34][35][3F][1C]
(write command)
After send command to MSR605
Yellow LED on, then swipe
card
write data to the magnetic card
