The MSR605 is a manual swipe magnetic card reader/writer designed for various applications including access control, timekeeping, banking, ID recognition, and credit verification. It offers a comprehensive solution for reading and writing magnetic stripe cards, supporting both high and low coercivity cards. The device is capable of encoding and verifying up to three tracks of data simultaneously and communicates with a host computer or other terminal via a USB interface.

Function Description:

The primary function of the MSR605 is to read and write data on magnetic stripe cards. It supports the ISO7811 standard for magnetic stripe cards. The device can operate in both read-only and read/write modes, making it versatile for different use cases. For reading, it can decode data from tracks 1, 2, and 3. For writing, it can encode data onto these same tracks. The MSR605 is designed to handle a wide range of magnetic coercivity, from 300 Oe to 4000 Oe, allowing it to work with various card types.

The MSR605 communicates with a host system using a USB interface. This allows for easy integration with existing computer systems. The device comes with a utilities test program that includes a Windows version, which can be used to verify its functionality and demonstrate card reading and writing capabilities. This program also serves as a basic card reading and writing application.

Important Technical Specifications:

Standard: ISO7811
Electrical Consumption:
- Typical operating: 350mA Max
- Additional for each writing track: 600mA
Communication: USB interface.
Power Supply: External switching power supply, AC 110~240V in / DC 9V, 2~3A out.
Mechanical:
- Body Material: ABS 94V-0 / Metal housing optional
- Swipe Method: Manual, single direction
- Outline Dimensions: 212L x 64W x 63H mm
- Weight: Approximately 1.4 Kg
Environment:
- Operation Temperature: -10°C to 60°C
- Operation Humidity: 10 to 85% humidity, non-condensing
- Storage Temperature: -30°C to 70°C
- Storage Humidity: 10 to 90% humidity, non-condensing
Performance:
- Read Circuit:
  - Track 1 & 3: 210 bpi
  - Track 2: 75 or 210 bpi
- Bit per Character: 5-7 bit per character
- Media Speed:
  - Read: 5-50 ips (read speed 5-40 ips for track 2 at 210 bpi)
  - Write: 5-30 ips
- Media Coercivity: Read/Write 300-4000 Oe Magnetic Card
- Media Thickness: 0.76-1.2mm
- Jitter Card:
  - Read bit to bit interval: <+/-15% card
  - Write bit to bit interval: <+/-10%, Sub interval <+/-12% at 30 ips
- Low Amplitude Card Read: 60% for both 75 & 210 bpi
- Error Rate: Read < 0.5%, Write < 0.8%
- Media Swipe Head Life: 1,000,000 passes for both read & write head
Configuration: MSR605 supports Read/Write for Tracks 1, 2, and 3 for both Hi-C and Lo-C cards.

Usage Features:

The MSR605 is designed for ease of use and integration. Its USB interface simplifies connectivity to a host computer. The device supports a range of commands for controlling its operations, including:

RESET: Resets the MSR605 to its initial state.
READ: Requests the MSR605 to read a swiped card and respond with the data.
WRITE: Requests the MSR605 to write a specified Data Block into a swiped card.
Communication Test: Verifies the communication link between the computer and the MSR605.
LED Control: Commands to turn all LEDs off, all LEDs on, or specific LEDs (Green, Yellow, Red) on.
Sensor Test: Verifies the functionality of the card sensing circuit.
RAM Test: Requests the MSR605 to perform a test on its onboard RAM.
Set Leading Zero: Configures the number of leading zeros to be written before the card data starts.
Check Leading Zero: Retrieves the current setting for leading zeros.
Erase Card: Erases data from selected tracks when a card is swiped.
Select BPI (Bits Per Inch): Sets the recording density for each track (e.g., 210 bpi or 75 bpi).
Read Raw Data: Reads a card swipe and sends raw data without ASCII decoding.
Write Raw Data: Writes raw data into a swiped card.
Get Device Model: Retrieves the model of the MSR605.
Get Firmware Version: Retrieves the firmware version of the MSR605.
Set BPC (Bits Per Character): Sets the bit per character for each track.
Set Hi-Co/Low-Co: Configures the MSR605 for writing high coercivity or low coercivity cards.
Get Hi-Co/Low-Co Status: Retrieves the current write status (Hi-Co or Low-Co).

The device's utility test program provides a user-friendly interface to access these functions, allowing users to activate them by clicking appropriate buttons and following on-screen instructions. The program also features auto-detection of the communication port.

Maintenance Features:

The MSR605 is designed for durability, with a media swipe head life of 1,000,000 passes for both read and write operations. This indicates a robust design intended for long-term use. The programmer's manual provides detailed information on data formats and communication sequences, which is crucial for developers integrating the MSR605 into their systems. This detailed documentation aids in troubleshooting and ensures proper implementation, minimizing potential maintenance issues related to software integration.

The warranty covers the MSR605 for one year after purchase, with a clear stipulation that any alteration, erasure, or modification of the device will void the warranty. This encourages users to maintain the device in its original condition and seek professional support if issues arise. The sensor and RAM tests provide built-in diagnostic capabilities, allowing users to quickly verify the proper functioning of critical components. The LED indicators also provide visual feedback on the device's status, which can assist in initial troubleshooting.
